Code: MG4240570

Blast freezer room Metos Ready RCSG-201-R-RIF RC

With Metos Ready RCS you immediately have available the optimal technologies and solutions to meet every request, optimize inventory and purchases, reduce waste…

List price €26,929.00
On order
With Metos Ready RCS you immediately have available the optimal technologies and solutions to meet every request, optimize inventory and purchases, reduce waste, and make your work easier, gaining time and opening new opportunities for you. The Ready cold rooms make the most of the available space, in the most diverse situations: from the laboratory to the canteen, to the cooking center, to the restaurant. Compatible with all laboratory or oven trolleys, they have been tested in compliance with the EN17032 standard, even with large loads and in the most demanding work situations.

Thanks to the optimization of the airflow, the result of in-depth research and numerous tests to obtain maximum results. Ready cells have achieved a significant increase in the quantity of product blast chilled and equally sharp reduction in the length of the work cycles. All this with significant energy savings: an advantage for the environment as well as for the budget.

STRUCTURAL CHARACTERISTICS: AISI 304 stainless steel panel construction with 80 mm-thick polyurethane foam insulation Stainless steel exterior (Scotch-Brite satin finish) Copper-aluminium evaporating coil, cataphoresis-painted with non-toxic epoxy resin, installed on the side, together with fairing that can be opened via a special safety key for easy and proper maintenance; all PED and UL-tested at a pressure of 30 bar. Highly ventilated evaporator to ensure the cooling system's maximum efficiency. Anti-condensation heating element fitted under the door seal. Door with a rubber sweeper seal, complete with closing hinges. Control-activated chamber sanitization system with active ions (HI-GIENE) (optional) Access ramp equipped with a liquid-collecting grille and filtering system External bumper to protect the control panel. Recessed or above-floor installation possible. Set up as standard for R452A refrigerant fluid. Cell fitted with easy-to-clean rounded corners and AISI 304 30/10 stainless steel internal bumpers All the surfaces, body's metal components and internal reinforcements are made of AISI 304 stainless steel and have been tested to withstand a saline environment for at least 800 hours. Easy-to-clean interior, thanks to the suspended evaporator that quickly removes the washing water, according to the indications of the NFS and UNI EN 14159 standards Cooling capacity expressed at evaporation temperature -25 °C and condensation temperature at + 45 °C.

EQUIPPED INTERIOR: Thick stainless steel internal bumper to prevent any trolley-related damage. Quick-release heated core probe with 4 measuring points.

COMMANDS, CONTROLS AND SAFETY DEVICES: Connectivity (optional) USB connection for uploading and downloading data/recipes 5" high-definition TOUCH display is easy to use Automatic storage at the end of the blast chilling cycle Electrical connections at the front of the padlocked panel Quick-release heated core probe with 4 measuring points

-,,1 door
-,,For remote cooled connection, cold machine not included
-,,Trolleys capacity n. Tot. 1x GN 1/1 - EN1
-,,Cooling capacity 120 kg (90min/+90…+3°C)
-,,Freezing capacity 80 kg (240min/+90…-18°C)
-,,Working temperature +3 / -40 °C
-,,Access ramp not included in the price Options, extra cost:
-,,Left hinged door PSC
-,,Ramp for 181, RCSG-_01
-,,Disassembled delivery 201-202
-,,Special voltages and frequencies on request.
-,,Dashboard on the right side and opposite hinged doors
General
Description Blast freezer room Metos Ready RCSG-201-R-RIF RC
Dimensions and Capacity
Product capacity 120kg/+90..+3,80kg/+90..-18
Inside measures mm 680x950x1820
Item width mm 1300
Item depth mm 1330
Item height mm 2100
Package volume 6.505 m3
Package dimensions (LxWxH) 240x156x154 cm
Net weight 450 kg
Package weight 570 kg
Technical information
Connection power kW 0.638
Connection voltage V 400
Number of phases 3N
Frequency Hz 50
Startup current A 2.87
Cooling capacity W 6890
Type of the refrigerant R452A/R448A/R449A
Sound level dB 69
Features
Hinge location right
GN size 1 trolley GN 1/1 - EN1
Temperature area ºC cooling capacity 120 kg (90min/+90…+3°C) / cooling capacity 120 kg (90min/+90…+3°C)
Cooling unit Remote cooled
Temperature probe Yes
Fill in trolleys Yes
Glass door No

Services and accessories

List price €1,303.00
